The online configurator is intended to allow users to configure the conveyor and options they need, which speeds up the RFQ process. Note: The configurator does not generate pricing.
Who Are You?
Product Type to Configure?
LEWCO CDLR25 chain driven live roller conveyor (2.5” dia. x 11ga. wall) is the standard choice for everyday pallet handling. Its rugged construction is well suited for loaded pallets, drums, and containers. This system uses a combination of powered roller conveyor and powered chain transfers. The standard T03C25 chain transfers shown in the corners below are pneumatic and have …
This system uses a combination of gravity roller conveyor, powered roller conveyor, and powered chain transfers. Conveyors are sized for a robust solution, using 2607 gravity lanes (2.6” dia x 7ga wall), and wide CDLR35 chain driven roller conveyor (3.5” dia x .300” wall). Heavy duty escapements comprised of pneumatic claw stops and RBB roller brakes are used to …
The CDZA Model conveyor is a zero pressure (products don’t touch), chain driven live roller conveyor. It can be built in 1.9” dia., 2.5” dia., and 2.62” dia. roller sizes to satisfy the load and width requirements. The conveyor is designed to accumulate loads such as large packages, pallets, drums, and containers, with no back pressure. These units can …
To complement our straight roller CDLR (Chain Driven Live Roller) conveyors, LEWCO Inc. builds Chain Driven Tapered Roller Curve (CDTRC) conveyors. The tapered shape of the rollers helps maintain the product orientation through the curve, because the tangential speed is greater toward the outside edge. The tapered rollers are well suited for loaded pallets, drums, packages, and …
Read More “Chain Driven Tapered Roller Curves from LEWCO, Inc.”
LEWCO Inc. recently supplied a baler manufacturer with a Cleated Medium Duty Slider Bed Belt Conveyor. This customer wanted to add an option to its product line for a conveyor that was integrated into their baler design. LEWCO Engineers worked closely with the baler company to design the conveyor to be easily installed on the …
LEWCO recently supplied a reusable container manufacturer with a pallet stacker/destacker. The manufacturer wanted to reduce fork truck traffic and also accumulate pallets. In stack mode, the pallets come out of a press one at a time, and are conveyed into the stacker on a Multi Strand Chain Conveyor. Once a stack of eight is …
LEWCO’s new semi-precision bearing option A6204 is now available as the standard option for all product lines utilizing 2.5 diameter, 11 gauge rollers and 2.63, 7 gauge rollers, including 2511 & 2607 straight gravity conveyors, 2511C & 2607C gravity roller curves, HG2511 spring loaded gate conveyors and finally 2511 & 2607 loose rollers. This bearing …
LEWCO Inc. has recently updated the standards which define our CDLR25 and CDLR26 models, increasing their durability while maintaining our competitive cost advantage. The improvements fall into (3) categories which are drive, frame and support improvements. DRIVE –In certain drive configurations, customers had reported issues with the rigidity of the drive mounting platform. By careful review …
Read More “Improvements to LEWCO CDLR, Chain Driven Live Roller Conveyors”
LEWCO Model TC1916 medium duty manual transfer cars allow product to be moved from one lane to another parallel lane within a system. These units are fixed to a set of tracks which facilitate easy movement and positioning in front on the lanes to be loaded or unloaded from the car. LEWCO 1.9″ Diameter 16 ga. …
Model MSCCH is a heavy duty version of the LEWCO standard multi-strand chain conveyor, still considered a drag chain conveyor however it incorporates C80 roller chain and 4 gage welded chain strand construction for extreme applications. In this application C2080 (double pitch) chain was used, so that attachments could be bolted to the chain to create zones. …
