SPS model heavy duty, structural steel, stationary ”H” style floor supports are easily adjusted and anchored. These supports feature a top pivot plate for applications requiring the conveyor to be set on an angle.
OVERALL WIDTH: 9″ – 66″
CONSTRUCTION: C4@5.4# inner channel and formed outer channel, 8ga;
C4@5.4# Welded channel crosstie; Base plate, 4ga.
TOP PLATE: Standard 4ga pivot top plate is available where adjustable pitch is required.
SUPPORT COLOR: OSHA safety blue powder (RAL 5017). All guarding is yellow (RAL 1023) and moving parts are bright red orange (RAL 2008). Optional colors available.
