BPD plates are designed to replace rollers in existing sections of gravity roller conveyor and are typically used as transition or positioning areas within the line.

BPD – DROP IN CONVEYOR FRAME STYLE BALL TRANSFER, STRAIGHT BALL PATTERN

WIDTH: 9″ – 51″

LENGTH: 2″, 6″, 9″, 12″

BALL CENTERS: 1-1/2” (staggered only), 2″, 3″, 4″, 6″

BALL TRANSFER: Standard 1″ diameter steel ball transfer with 1/4-20 UNC stud
mount. Optional ball transfers include stainless steel surface, nylon surface, and
steel surface with flange.

BALL COVER: Standard is no ball cover. Optional ball cover available.

FRAME: Standard 12ga formed steel plate with 7/16″ holes for attaching to rails.

GUARDRAIL: Standard is no guardrail. Optional side and end guardrails are
available on one side or both sides.

BALL TABLE COLOR: Powder coated blue (RAL 5017). Click HERE to see other standard color options. Custom colors also available.

Ball Table Cover Plate

  • 12ga. formed steel
  • Note: not intended for walking on.
