Wheel Rail Conveyors provide an economical means of conveying products in flow racks and other gravity applications. WRE is a medium duty rail that can be utilized as a tote, box, or carton rail. The angle frames are also ideal for floor mounted applications, while the staggered wheel pattern conveys irregularly shaped loads.
LENGTH: 12″ – 120″
WHEEL CENTERS: 2″, 3″ WRD,WRF. 1-1/2″, 2″ WRE.
WHEEL: Standard 1.9″ diameter steel, oiled, 75 lbs dynamic load. Optional
wheels available with 100 lbs or 2000 lbs dynamic load.
WHEEL SURFACE: Standard zinc plated. Optional orange urethane.
FRAME: Standard steel formed angle, 2″ x 1″ x 12ga.
END STOP: Standard no end stop included. Optional end stop includes
CONVEYOR COLOR: OSHA safety blue powder (RAL 5017). All guarding is yellow (RAL 1023) and moving parts are bright red orange (RAL 2008). Optional colors available.
