Turntable conveyors rotate unit loads to change the direction of travel while maintaining product orientation. They can also be used to reverse the orientation of a product or allow a pass through depending on application requirements.
BETWEEN FRAMES: 27″ – 61″
LENGTH: 24″ – 48″
ROLLER CENTERS: 4.5″
HEIGHT ELEVATION: 13″ – 36″. For elevations below 13″, see model NPTG25LP.
ROLLERS: 2.5” diameter, 11ga mile steel tube with 11/16″ hex axle, spring retained, with precision, greased packed ABEC bearings.
- Optional:
- Cotter pin retained axle
- Galvanized roller tube
- Polyurethane roller sleeve
ROTATION: 360 degrees, detented at 90 degree increments.
CONSTRUCTION: Formed 8ga. channel rails with roller set 1/4″ high. Turntable is 3/8″ plate with a slewing ring center bearing.
TURNTABLE COLOR: Powder coated blue (RAL 5017). Click HERE to see other standard color options. Custom colors also available.
ADDITIONAL OPTIONS:
- Guardrail
- End Stops
- Custom sizes and features available. Please consult a LEWCO Applications Engineer for more information.
