SPH model heavy duty, stationary ”H” style floor supports are easily adjusted and anchored. These supports feature a top pivot plate for applications requiring the conveyor to be set on an angle.
OVERALL WIDTH: 7″ – 78″
CONSTRUCTION: Formed steel inner and outer channels, 8ga; Welded channel crosstie, 12ga; Base plate, 8ga.
TOP PLATE: Standard 8ga pivot top plate is available where adjustable pitch is required.
SUPPORT COLOR: OSHA safety blue powder (RAL 5017). All guarding is yellow (RAL 1023) and moving parts are bright red orange (RAL 2008). Optional colors available.
